EXTRUTEX Drinking Straw Packing Line

Automatic Individual Straw Wrapping and High-Capacity Bulk Bagging

The EXTRUTEX Drinking Straw Packing Line is an integrated two-stage packaging solution designed for manufacturers of plastic drinking straws, paper straws and other compatible straw products. The system combines the EX-031QS Single-Straw Wrapping Machine with the EX-850XGLJ Automatic Bulk Bagging Machine, creating a coordinated process that individually wraps each straw before counting and packing the finished products into larger outer bags.

Designed for commercial straw production and food-service packaging operations, this configuration helps manufacturers deliver hygienically packaged individual straws in organized, retail-ready or distribution-ready bulk quantities. Depending on the product specification and packaging requirements, the outer bagging stage can be configured for approximately 50–500 individually wrapped straws per bag.

EXTRUTEX combines Austrian design expertise with manufacturing operations in Nanjing and Shanghai, China. Our approach focuses on practical industrial engineering, reliable automation, production efficiency and packaging flexibility for international customers.

1. Product Overview

Integrated Individual Wrapping and Bulk Packaging

The EXTRUTEX Drinking Straw Packing Line combines two specialized packaging machines to handle different stages of the packaging process. The first machine wraps individual straws in suitable packaging material. The second machine receives the wrapped straws, arranges and counts them according to the selected batch quantity, and packs them into larger bags.

Separating the operation into primary and secondary packaging stages gives manufacturers greater flexibility when selecting individual wrapping materials and bulk bag dimensions. It also provides a structured workflow for facilities that supply supermarkets, restaurants, beverage outlets, catering companies, distributors and food-service packaging businesses.

EX-031QS Single-Straw Wrapping Machine

The EX-031QS is designed to wrap individual drinking straws using paper or BOPP film. With a stated operating speed of approximately 200–600 pieces per minute, it supports high-volume primary packaging applications.

The machine uses back-side sealing and automated feeding, sealing and cutting functions. Servo-driven mechanisms help coordinate packaging movements, while photocell tracking can support accurate positioning of printed packaging material where compatible registration marks are used.

The system accommodates straws with diameters of approximately 4–12 mm and lengths of 150–280 mm. Other sizes may be available by order, subject to engineering confirmation and any required tooling or machine adjustments.

EX-850XGLJ Automatic Bulk Bagging Machine

The EX-850XGLJ handles secondary packaging after the individual straws have been wrapped. It forms, fills and seals larger bags containing a selected quantity of individually packaged straws, with a stated packing range of approximately 50–500 pieces per bag.

The machine supports adjustable packaging speeds of approximately 3–10 bags per minute. Its specified maximum film width is 850 mm, while the listed bag dimensions are approximately 80–250 mm in width and 90–600 mm in length. The final bag format and practical output depend on the selected bag size, product quantity, material characteristics and operating settings.

2. How the Drinking Straw Packing Line Works

1. Straw feeding: Straight drinking straws are supplied to the individual wrapping machine using the appropriate feeding arrangement.
2. Packaging material feeding: Paper or BOPP packaging material is fed into the EX-031QS wrapping section. Compatible printed film can use photocell registration where the material has suitable tracking marks.
3. Individual wrapping: Each straw is enclosed in its own packaging material, and the back-side sealing system closes the wrapper.
4. Cutting and discharge: The wrapping machine cuts the packaging to the required format and discharges the individually wrapped straws.
5. Transfer to secondary packaging: The wrapped straws are supplied to the bulk bagging stage through the selected transfer and feeding arrangement. The interface and any accumulation or synchronization equipment should be confirmed for the final line layout.
6. Counting and batching: The EX-850XGLJ organizes the wrapped straws into the required batch quantity, generally within the specified range of 50–500 pieces per bag.
7. Outer bag formation and sealing: The bulk packaging machine forms the outer bag from compatible film, fills it with the selected quantity, and seals the package.
8. Finished product discharge: Completed bags are discharged for inspection, carton packing, palletizing or subsequent distribution.

For a production line to operate continuously, the two machines must be matched to the required product rate, batch quantity, material specifications and downstream handling arrangements. Actual line throughput is determined by the slower stage and the operating conditions of the complete system.

3. Key Features and Advantages

Individual Protection for Every Straw

Individual wrapping provides a separate packaging layer around each straw. This format is useful for food-service applications where single-use distribution, convenient handling and organized storage are important. The wrapping material and package design should be selected according to the intended market, applicable food-contact requirements and customer specifications.

Flexible Primary Packaging Materials

The EX-031QS supports paper or BOPP material according to the supplied machine specification. These options enable manufacturers to select packaging that matches their branding, product presentation, material availability and customer requirements. Material thickness, width, sealing characteristics and print registration compatibility should be verified before production.

Adjustable Bulk Bag Quantities

The EX-850XGLJ is specified for approximately 50–500 straws per outer bag. This provides flexibility for different wholesale quantities and distribution formats. The selected batch size can be matched to customer orders, carton dimensions and handling requirements, subject to confirmation of the machine's configured operating range.

Servo-Driven Motion Control

The individual wrapping machine uses servo motors to coordinate relevant machine movements. Servo control supports adjustable motion and repeatable operating sequences, helping the machine manage material feeding, package formation and cutting. The bulk packaging machine also uses servo-driven operation as listed in its electrical component specification.

Touchscreen Operation

Touchscreen interfaces provide an operator control point for setting and monitoring supported machine functions. Depending on the final configuration, operators can adjust available operating parameters, select packaging settings and monitor machine status. Actual interface functions depend on the installed control program and supplied machine version.

Photocell Tracking

Photocell systems can detect packaging registration marks and help coordinate cutting positions on compatible printed material. Correct operation depends on print-mark contrast, material quality, sensor adjustment and machine setup. Unprinted packaging may use a different setup where supported.

Material and Product Detection

Automatic detection functions can monitor selected product or packaging-material conditions and stop the machine when a monitored supply is missing. These functions can help reduce empty packaging and certain avoidable production errors. The exact detection points and stop conditions should be verified against the final machine configuration.

Integrated Primary and Secondary Packaging

Combining two packaging stages in one production solution reduces the need to manage individual wrapping and bulk bagging as unrelated operations. With a properly engineered transfer arrangement, manufacturers can organize the packaging workflow, improve production coordination and maintain a consistent finished-product format.

4. Technical Specifications

EX-031QS Single-Straw Wrapping Machine

EX-850XGLJ Automatic Bulk Bagging Machine

Complete Line Power and Installation

Technical note: Specifications are based on the supplied machine data. Confirm final dimensions, electrical requirements, production configuration and included auxiliary equipment with EXTRUTEX before placing an order. The source information also contains a separate dimension entry of 2000 × 800 × 1200 mm without a clearly identified component; it has therefore not been assigned to either machine.

5. Main Electrical Components

The following tables list the electrical components and brands specified in the supplied equipment data. Equivalent components, revisions or alternatives should be confirmed in the final bill of materials and purchase agreement.

EX-031QS Single-Straw Wrapping Machine

EX-850XGLJ Automatic Bulk Bagging Machine

6. Applications and Suitable Markets

The EXTRUTEX Drinking Straw Packing Line is suitable for manufacturers that need to individually wrap straws and then prepare them in larger counted bags for commercial distribution.

• Food-service packaging: Individually wrapped straws for restaurants, cafes, catering operations and takeaway businesses.
• Beverage and hospitality supply: Bulk bags of individually packaged straws for beverage service, hotels and hospitality distributors.
• Supermarket and retail supply: Packaging workflows for private-label and branded straw products, subject to the selected outer-bag presentation.
• Wholesale distribution: Counted batches for wholesalers, importers, food-service distributors and institutional customers.
• Straw manufacturing factories: Primary and secondary packaging equipment for integration with compatible straw production and finishing processes.
• OEM and private-label production: Packaging configurations adapted to customer requirements, approved dimensions and compatible printed materials.

Product suitability depends on straw geometry, material, stiffness, surface condition, packaging dimensions and the feeding method. Paper, PLA, PP and other straw types should be evaluated against the actual machine configuration and production requirements before commercial operation.

7. Packaging Materials and Product Compatibility

The individual wrapping stage is specified for paper or BOPP film. The outer bagging stage is specified for film with a thickness of approximately 0.03–0.06 mm. The primary and secondary packaging materials serve different purposes and should be selected independently according to package performance and customer requirements.

Before selecting packaging material, manufacturers should consider sealability, stiffness, friction, print quality, film tracking, storage conditions, transportation requirements and applicable market regulations. Printed film requires suitable registration marks and sensor compatibility if print-position tracking is required.

Material specifications should be validated through machine trials. The listed film thickness and dimensional ranges are equipment reference values rather than a guarantee that every material will run at the maximum stated speed under every operating condition.

8. Production Efficiency, Operation and Maintenance

Efficient operation depends on stable straw feeding, consistent wrapping-material tension, correct sealing temperatures where applicable, accurate sensor positioning and a well-matched transfer arrangement between the two machines. Operators should establish approved production settings for each straw size and packaging material before starting routine production.

Routine maintenance should include cleaning product-contact and material-guiding areas, inspecting sealing and cutting components, checking sensors, verifying drive and transmission components, and examining electrical connections according to the equipment manual. Packaging-material changes and product-size changes should follow the machine's approved setup procedures.

Operators should be trained in machine startup, safe stopping, jam clearance, emergency-stop use, material loading and routine inspection. Guards and safety devices must remain in place during operation. Isolate electrical and pneumatic energy as applicable before performing maintenance or clearing hazardous obstructions.

EXTRUTEX can discuss the intended product, packaging format and production target with customers to help establish the appropriate configuration. Any requested changes to dimensions, controls, electrical standards or material handling should be reviewed before manufacturing.

9. Choosing the Right Straw Packaging Configuration

The two-stage EXTRUTEX line is intended for applications where each straw needs its own wrapper before multiple finished straws are grouped into an outer bag. This differs from direct group packing, where unwrapped straws are counted and placed directly into a bag.

Selection should be based on the finished package rather than speed alone. The best configuration is the one that consistently meets the customer's straw dimensions, individual wrapping requirements, outer-bag quantity, material specifications and target production rate.

10. EXTRUTEX Design and Manufacturing

EXTRUTEX develops industrial equipment with an Austrian design approach and manufacturing in Nanjing and Shanghai, China. Our focus is on practical machine engineering, configurable production solutions and equipment for international plastics, packaging and manufacturing markets.

For the Drinking Straw Packing Line, configuration discussions can cover straw dimensions, wrapping material, outer-bag size, required batch quantity, target output, electrical supply and factory layout. These details help establish a suitable equipment arrangement and clarify any additional feeding, transfer or collection equipment required for the intended production workflow.

11. Request a Quotation for the EXTRUTEX Drinking Straw Packing Line

Contact EXTRUTEX to discuss your drinking straw packaging requirements. To help us prepare a suitable proposal, provide the following information:

• Straw material and product type, such as PP, PLA, paper or another compatible material.
• Straw diameter, length and any special product geometry.
• Preferred individual wrapping material: paper or BOPP film.
• Required number of straws per outer bag, within the intended operating range.
• Outer-bag dimensions, film specification and printing requirements.
• Target production output and expected operating schedule.
• Factory electrical supply, available installation space and transfer-layout requirements.

With these details, EXTRUTEX can review the required configuration, confirm technical compatibility and discuss the appropriate equipment arrangement for your straw packaging operation.
