TS-CU-1002M Ca/Zn Stabilizer for PVC Wires & Cables 90°C–106°C
TS-CU-1002M
Ca/Zn Stabilizer for PVC Wires & Cables 90°C–106°C
Technical Data Sheet
| Property | Specification |
| Brand | EXTRUTEX® |
| Product Name | TS-CU-1002M |
| Product Type | Calcium Zinc PVC Stabilizer |
| Appearance | White to pale yellow powder |
| Recommended Dosage | 4–6 PHR |
| Cable Temperature Rating | 90°C–106°C |
| Applicable Standards | GB 90°C (HI), UL 90°C–105°C |
| Application | PVC wire and cable insulation and sheathing |
| Thermal Stability | Excellent |
| Initial Color | Excellent |
| Electrical Insulation | Excellent |
| Compatibility | Excellent with common plasticizers |
| Volatile Matter | ≤ 2.0% |
| Moisture Content | ≤ 1.0% |
| Bulk Density | 0.45–0.80 g/cm³ |
| Processing Method | High-speed mixing and extrusion |
| Heavy Metal Content | Free of lead and cadmium |
| Compliance | RoHS, REACH |
| Packaging | 20 kg / 25 kg kraft paper bag with PE liner |
| Storage Conditions | Cool, dry, well-ventilated place |
| Shelf Life | 12 months |
TS-CU-1002M Ca/Zn Stabilizer for PVC Wires & Cables 90°C–106°C
Description
EXTRUTEX® TS-CU-1002M
Ca/Zn Stabilizer for PVC Wires & Cables 90°C–106°C
GB 90°C (HI) / UL 90°C–105°C Cable Compounds
Product Description
EXTRUTEX® TS-CU-1002M is a premium calcium-zinc (Ca/Zn) heat stabilizer specially developed for high-performance PVC wire and cable compounds rated from 90°C to 106°C.
This lead-free powder stabilizer is designed for PVC insulation and sheathing used in GB 90°C (HI) and UL 90°C–105°C cable applications. It delivers excellent long-term thermal stability, superior electrical insulation, high initial color, and exceptional processing consistency during extrusion.
With a recommended dosage of 4–6 PHR, TS-CU-1002M helps manufacturers produce environmentally friendly cable compounds that meet stringent international standards while maintaining excellent mechanical and dielectric properties.
Like a silent guardian within the compound, TS-CU-1002M protects PVC against the scorching breath of the extruder, preserving strength, flexibility, and color through every meter of cable produced.
Key Features
Lead-free calcium zinc stabilizer
Suitable for 90°C to 106°C heat-rated cable compounds
Designed for GB 90°C (HI) and UL 90°C–105°C standards
Excellent static and dynamic thermal stability
Superior initial whiteness and color retention
Outstanding electrical insulation properties
Low plate-out and clean processing
Excellent compatibility with DOTP, DINP, and TOTM
Supports high-speed extrusion
Improves tensile strength and elongation
Low odor and environmentally friendly
RoHS and REACH compliant
Applications
UL 90°C building wire
UL 105°C appliance wiring material (AWM)
GB 90°C (HI) cable compounds
Automotive wire insulation
Power cable insulation and sheathing
Control and instrumentation cables
Communication cables
Industrial electrical cords
Heat-resistant PVC compounds
Recommended Formulation
| Material | PHR |
|---|---|
| PVC Resin | 100 |
| EXTRUTEX® TS-CU-1002M | 4–6 |
| Plasticizer (DOTP/DINP/TOTM) | 30–70 |
| Calcium Carbonate | 0–30 |
| Lubricants | 0.2–1.0 |
| Pigments | As required |
| Flame Retardants | Optional |
Technical Data Sheet
| Property | Specification |
|---|---|
| Brand | EXTRUTEX® |
| Product Name | TS-CU-1002M |
| Product Type | Calcium Zinc PVC Stabilizer |
| Appearance | White to pale yellow powder |
| Recommended Dosage | 4–6 PHR |
| Cable Temperature Rating | 90°C–106°C |
| Applicable Standards | GB 90°C (HI), UL 90°C–105°C |
| Application | PVC wire and cable insulation and sheathing |
| Thermal Stability | Excellent |
| Initial Color | Excellent |
| Electrical Insulation | Excellent |
| Compatibility | Excellent with common plasticizers |
| Volatile Matter | ≤ 2.0% |
| Moisture Content | ≤ 1.0% |
| Bulk Density | 0.45–0.80 g/cm³ |
| Processing Method | High-speed mixing and extrusion |
| Heavy Metal Content | Free of lead and cadmium |
| Compliance | RoHS, REACH |
| Packaging | 20 kg / 25 kg kraft paper bag with PE liner |
| Storage Conditions | Cool, dry, well-ventilated place |
| Shelf Life | 12 months |
Processing Benefits
TS-CU-1002M offers:
Extended thermal protection during long extrusion runs
Reduced discoloration and degradation
Improved insulation resistance and dielectric strength
Lower die build-up and cleaner machinery
Better surface finish and gloss
Stable viscosity and consistent output
Enhanced mechanical durability
Packaging and Storage
Net Weight: 20 kg or 25 kg per bag
Packaging: Multi-layer kraft paper bag with moisture barrier liner
Shelf Life: 12 months from manufacturing date
Storage: Keep tightly sealed in a dry area away from heat and humidity
EXTRUTEX® Brand
EXTRUTEX® develops advanced additives and processing solutions for PVC, polymer compounding, and extrusion industries worldwide. TS-CU-1002M is part of the EXTRUTEX® premium wire and cable stabilizer series, designed for high-temperature and environmentally compliant applications.
Website: https://extrutex.com
Features of OUR Ca/Zn Stabilizers
These stabilizers carry a quiet brilliance in their chemistry — qualities that make PVC behave not just well, but beautifully. Their strengths unfold like a list of promises:
• Excellent heat stability
They stand firm in the furnace of processing, guarding PVC against the harsh bite of thermal decay. Even under long residence times and high-output conditions, they keep the melt calm, steady, and true.
• Excellent processing
A formulation that flows like a well-rehearsed story — smooth, predictable, effortless. Machines run cleaner, extrusion runs longer, and operators breathe easier.
• High output rates
These stabilizers encourage speed. They let production lines surge forward, pushing greater volumes without sacrificing stability, gloss, or dimensional accuracy.
• Excellent plate-out properties
They keep the metal clean — die lips, barrels, calibrators — all free from waxy buildup. No residue, no streaks, no interruptions. Just pure, disciplined processing.
• Excellent dimensional stability
Pipes and fittings emerge with the confidence of perfect geometry. Sizes remain loyal to standards, resisting distortion, warpage, or shrinkage.
• Excellent surface finish
A stabilizer that leaves behind a sheen — a smooth, glasslike finish that speaks of controlled melt flow and refined lubrication balance.
APPLICATIONS:
